The Rust is in there

25 Jan 2016

This is not a rust file, Mulder.

This is not a rust file, Mulder.

Ok, I’m done. Promise.

What in there could be librarized?

In the previous post, I stated that not relying on a framework was freeing the developer from the framework constraints. For instance, one can choose to have such or such result in memory because it fits.

It also allows the developer to make use of very compact types instead of a handful of generic purpose ones.

But these are not choices you want to have to make all the time.

Basically, what I have done so far is spent days — weeks literally — on a single SQL group-by query a data scientist would have crafted in less than half a minute :)

One of the things I’m trying to assess is what kind of tools would make sense to develop as a longer term goal. I’m thinking DSL, or a SharkSQL clone or a notebook kernel, or whatever.

So for now, as a developer, I perform high-level optimisations manually. But I will try to stay in the realm of optimisations that a semi-automatic optimiser could find.

  SELECT SUBSTR(sourceIP, 1, X), SUM(adRevenue)
    FROM uservisits
GROUP BY SUBSTR(sourceIP, 1, X)

Somebody on twitter remarked that when I was contemplating storing the IP characters on half-bytes, I could go all the way and just store the IP on a proper way, that is a four-byte integer.

This is true. But both approach are unfair to the optimizer. You and I know what to expect in a string sourceIP field (assuming the data is clean). But there is no way an automatic optimizer can do the right thing here.

On the other hand, using a fixed array of bytes to store the result of a SUBSTR is fair game. An optimiser could reasonably decide that.

As for the storage location decision (“this will fit in memory”), it’s a bit harder. I only knew the storage requirement because there were given in the paper, by somebody who already had the query run. We could imagine various strategies:

Anyway, all this is a long way down the road from here.

Introducing Dazone

The code is here: https://github.com/kali/dazone . The README gives instructions about how to run the bench.

Let’s have a look at simple runner for Query 2: https://github.com/kali/dazone/blob/master/src/bin/query2_simple.rs

The runner I actually use is query2.rs. It allows to tweak many parameters and strategies, but let’s keep it minimal.

extern crate dazone;

use dazone::crunch::*;
use dazone::short_bytes_array::*;
use dazone::data::pod::UserVisits;

fn main() {
    let input = dazone::files::bibi_pod::<UserVisits>("5nodes", "uservisits", "text-deflate");
    let map = |visit: UserVisits| Emit::One(Bytes8::prefix(&*visit.source_ip), visit.ad_revenue);
    let reduce = |a: &f32, b: &f32| a + b;
    let mut aggregator = ::dazone::crunch::aggregators::MultiHashMapAggregator::new(&reduce, 256);
    MapOp::new_map_reduce(map)
        .with_progress(true)
        .with_workers(16)
        .run(input, &mut aggregator);
    aggregator.converge();
    println!("### {} ###", aggregator.len());
}

Input, Data and BIBIs

let input = dazone::files::bibi_pod::<UserVisits>("5nodes", "uservisits", "text-deflate");

This works, because we have:

https://github.com/kali/dazone/blob/master/src/data/pod.rs#L10

#[derive(RustcDecodable,RustcEncodable,Debug)]
pub struct UserVisits {
    pub source_ip: String,
    pub dest_url: String,
    pub visit_date: String,
    pub ad_revenue: f32,
    pub user_agent: String,
    pub country_code: String,
    pub language_code: String,
    pub search_word: String,
    pub duration: u32,
}

bibi_pod is actually quite generic. It knows about the file structure conventions, so using another “table” or dataset size (the “5nodes” bit) does not require any change. The actual pod type, UserVisits, is a type parameter, so we are generic on that too. The format combination (encoding and compression) is parsed, so bibi_pod knows how to read from various compression schemes and encoding formats. It also know where to read the files accordingly.

As for its return value, it’s actually:

Box<Iterator<Item=Box<Iterator<Item=UserVisits>>>>

That’s a Boxed Iterator on Boxed Iterator of UserVisits… bibi for short :)

We use two levels of iterations. The top level splits data on big chunks (each file a chunk) and the lower level is the record. It is actually quite convenient to keep these two levels around. We load the data file by file, and we process it by chunk anyway.

As for the Box bit, let’s just ignore that for now. Seasoned Rust developers will known why it’s there.

Map/Reduce

Well, map/reduce stays a relevant way to consider these kind of issues. This is actually a bit of code that predates Query 2 and that I was able to reuse without huge modifications. What we are looking at here is a simple, in-process map/reduce implementation. It does not support migrating work to other processes or nodes. We will come to that, but we will be using timely dataflow.

let map = |visit: UserVisits| Emit::One(Bytes8::prefix(&*visit.source_ip), visit.ad_revenue);
let reduce = |a: &f32, b: &f32| a + b;

We will map each input file to extract the 8 bytes prefixes and the associated revenue. The prefix will serve as a key, and the reduce stage will sum up the revenue.

Emit is the return value of our map function. In my initial implementation, the map function was returning an Iterator, to be able to return any number of pairs. But in the Query2 case, each record generates one and only one pair. Dealing with an Iterator in that case was a bit expensive, so I introduced a Zero or One or Many enumeration. This is a terribly premature optimisation in our present case, but it predates work on Query2.

Bytes8 is one of the types I had to make to deal with the 8-byte long string. Think of it as similar to SQL’s CHAR(8). Now, Rust does not support generics parameterized by values: I can’t have define CHAR<length> and use it with CHAR<8>. Macros are less a satisafactory solution, but that will work.

See https://github.com/kali/dazone/blob/master/src/short_bytes_array.rs if you feel really compelled to.

Running it

Now let’s plug everything together and run it.

let mut aggregator = ::dazone::crunch::aggregators::MultiHashMapAggregator::new(&reduce, 256);
MapOp::new_map_reduce(map)
    .with_progress(true)
    .with_workers(16)
    .run(input, &mut aggregator);
aggregator.converge();
println!("### {} ###", aggregator.len());

The MultiHashMapAggregator is a bit complex. There are simpler, switchable, more wasteful implementations of the aggregation. Basically, the idea is to have a first stage of the aggregation happening just after the map in the same thread and in the same loop. It will construct partially reduced intermediary results ; then we will merge them with the “big” map. This is similar to how a Combiner works in Hadoop, if you remember. But here, intead of IO bandwidth, what we are trying to avoid is a constant struggle for a global Mutex on the global HashMap holding the result.

This aggregator is called MultiHashMap because its global Map is also sharded to help with concurrency accesses (a bit like the ConcurrentHashMap from the JVM).

MapOp will shove the data in the mapper and push the result to the aggregator. We have a chance to configure it a bit, showing the progress bar and using 16 workers.

The converge() call can be disregarded. The last line prints the number of groups to the console.

Thought on Reusability

All in all, this is not too bad.

What’s next

Next time, we will have a look at input formats and how they affect the performance.

Rust and BigData series:

  1. Rust, BigData and my laptop
  2. The rust is in there
  3. Let’s optimize
  4. Hashes to hashes
  5. Embrace the glow cloud
  6. Query2 in timely dataflow
  7. Query2 in differential dataflow
